Artificial Materials

Olivier Vanbésien, Lille University, France

ISBN : 9781848213357

Publication Date : March 2012

Hardcover 368 pp

177.00 USD



In the field of electromagnetic and/or optical waves, the concept of “artificial material” covers any fabricated device, be it metallic, dielectric or metal-dielectric, enabling a varyingly complex control of wave propagation in a chosen wavelength range. A common point to all approaches is that the structural scale of the building blocks of a new material is proportional to its operating wavelength. From this first principle stem two relatively distinct research paths, “photonic crystals” (or photonic/electromagnetic materials with a band gap) and “metamaterials”.

This book discusses these artificial materials, focusing on photonic crystals (PC) and metamaterials (MM). The first part is devoted to design concepts: negative permeability and permittivity for negative refraction, periodic structures, transformation optics. Part 2 concerns PC and MM in a band gap regime: from cavities and guides to high impedance surfaces. Abnormal refraction, less than one and negative, in PC and MM are studied in the third part, addressing super-focusing and cloaking. Then, applications for telecommunications, lasers and imaging systems are explored.


Part 1. A Few Fundamental Concepts
1. Definitions and Concepts.
2. The Metamaterial Approach – Permeability and Permittivity Engineering.
3. Photonic Crystal Approach – Band Gap Engineering.
4. Transformation Optics.
Part 2. Materials Used in a Band Gap Regime.
5. Point and Extended Defects in Photonic Crystals.
6. Routing Devices made from Photonic Crystals.
7. Single Negative Metamaterials.
Part 3. Materials in an Abnormal Refraction Regime (n < 1 and n < 0)
8. Two-dimensional Microwave Balanced Composite Prism.
9. Metal-dielectric Materials – from the Terahertz to the Visible.
10. Abnormal Refraction in Photonic Crystals.
11. A Photonic Crystal Flat Lens at Optical Wavelength.
12. Wave-controlling Systems – Towards Bypass and Invisibility.
Part 4. Moving Toward Applications
13. Guiding, Filtering and Routing Electromagnetic Waves.
14. Antennas.
15. Optics: Fibers and Cavities.
16. Detection, Imaging and Tomography Systems.

About the authors

Olivier Vanbésien received a doctorate in quantum devices in 1991. He then joined the Institut d’Electronique, de Microélectronique et de Nanotechnologie (IEMN) and was appointed Professor of Electronics at Lille University in France in November 2000. His interests concern metamaterials and photonic crystals, exploring abnormal refraction from terahertz down to optics.
